Initial RAID Array Information

RAID Storage ArrayNumber of Disks: 2

Disk 1
Model: ST31000340AS
P/N: 9BX158-303
F/W: SD15
Date: 08363
Site: WUXISG
S/N: 5QJ….

Disk 2
Model: ST31000340AS
P/N: 9BX158-303
F/W: SD15
Date: 08366
Site: AMKSPR
S/N: 3QJ….

Notes: Customer says that RAID 1 array suddenly reverted to past state and that all data from past year was lost.

Initial RAID 1 Array Data Recovery Diagnostic Phase

Step 1: Both drives connected to PC-3000 and powered on.  (both drives correctly ID and show correct size)

Step 2: Test read/write of sectors to verify translator (both drives pass)

Step 3: Begin cloning procedure of both drives.  Drive 1 has some slow reading sector areas, however after 2 passes is 100% cloned.  Drive 2 has many slow reading sector areas, and many bad sectors.  Cloning put on hold until customer approves quote.

Step 4: Analyze file system to determine which drive contains target data.  (Disk 2 has 160Gb more data allocated in file table than Disk 1.  It appears that disk 1 went offline approx. 1+ years ago, but came back online as of May 21st when Disk 2 failed)

Notify customer and recommend recovery of Disk 2 only at this point.  Quoted price $500. (Approved)

RAID 1 Data Recovery Phase

Step 1: Initial imaging performed using low timeout setting. (Approx 99% of data extracted)

Step 2:  Second pass imaging using higher timeout setting.  (Drive keeps crashing out and doesn’t reach ready state after soft or hard reset)

Step 3:  Settings adjusted to power cycle drive after reading error.  (Imaging completed after 2 days, approx 3000 unread sectors)

Step 4: Clear sector map, adjust read error jump size to 1, Image unread sectors.  (completed after 1 day with approx 150 unread sectors)

Step 5: Adjust imaging process to reverse setting, clear map, run 4th pass imaging. (completed after a few hours with only 70 unreadable sectors left)

Step 6:  Analyze logical data to verify contents.

Data Recovery 99.9999999% success.
